IMCOS-7016-V2 PA/GA Remote control panel box with handheld or gooseneck microphone


·         The panel includes:
• 25 pushbuttons polycarbonate keypad;
• microphone with push to talk feature;
• up to 6 illuminated emergency call pushbutton with protective cover against accidental use;
• 1 dimmer for polycarbonate keyboard light;
• 1 dimmer for adjusting LED light intensity;
• 1 volume control for external loudspeaker when integrated with talk back system

·         Different microphone options:
• without microphone (IMCOS-7016-V2-0)
• handheld microphone (IMCOS-7016-V2-1L)
• gooseneck microphone (IMCOS-7016-V2-2L)

·         Multiple remote control panels can be controlled by a proprietary network. RS 485 data interface to the main unit

·         Local loudspeaker bypass to avoid audio feedback

·         Redundant power lines



Request for quotation

Description

IMCOS-7016-V2 is a remote control panel designed for announcements, pre-recorded messages broadcast through the Public
Address as well as talk back main station.

The panel is integrated with up to seven pushbuttons for alarm tones broadcast customizable upon request.

Designed to meet and exceed the requirements of ABS, BV, CCS, DNV-GL, LR, RINA, Norsok and UKOOA/PFEER

Material Aluminium – grey colour RAL 7001
Mounting Wall mounting
Cable glands Standard: 2x PG21 + 3x PG29
+1x PG21 optional for receiving speaker
Wiring Terminal strip inside
Dimensions Height 400 mm, width 230 mm, depth 110 mm
Weight 3,7 Kg

Datasheet IMCOS-7016-V2 PA/GA Remote control panel box with handheld or gooseneck microphone

Download the datasheet below.

 IMCOS-7016-V2 PA-GA Remote control panel box with handheld or gooseneck microphone
