IMCOS-6080 Relay unit with free contact and power contacts
• Coated steel – turquoise colour Ral 6034
• 1 N/O free contact
• 2 power contacts (24 V DC or 220 VAC or 120 VAC according to relay unit power)
•
Different powering options available:
• 24 V DC (IMCOS-6080-1);
• 220 V AC (IMCOS-6080-2);
• 120 V AC (IMCOS-6080-3)
• Ingress Protection IP55
Request for quotation
Description
IMCOS-6080 is a wall mounting relay unit, suitable for ship applications. The box is complete with 1 N/O free contact, available to connect external A/V columns or other external audio/visual device, and 2 powered contacts, suitable for driving external A/V devices.
This device is suitable for both IMCOS analogue automatic telephone system and IMCOS self powered telephone network.
DNV type approval.
Material
Coated steel – turquoise colour Ral 6034
Mounting Wall mounting
Cable inlet Bottom side cable inlet
Cable glands 4 x PG16 (3/4”)
Wiring Screw terminals inside
Power consumption 10 W. Max power relay: 4A (total)
Dimensions Height 185 mm, width 205 mm, depth 65 mm
Powering 24 VDC (-1), 220 VAC (-2), 120 VAC (-3)
Weight (max) 1,8 Kg
Ingress protection IP55
